753-509 | WAGO

Output module, Outputs: 2, (W x H x D) 12 x 100 x 698 mm, 753-509

Order No.: 44P5711
EAN: 4045454394554
MPN:
753-509
Series: 753
753-509 WAGO Digital modules Image 1
753-509 WAGO Digital modules Image 2
753-509 WAGO Digital modules Image 3
Image may differ
Unit Price (€ / pc.)
101.4118 € *
Available: 0 pcs.
Leadtime: 5 Weeks **
Total Price:
101.41 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
101.4118 €

Digital output, 753-509, WAGO

2-channel digital output, 230 VAC, 0.3 A, Solid-state.

Features

  • This digital output module transmits control signals from the automation device to the connected actuators
  • The semiconductor output is electrically isolated from the control side
  • Power supply for the outputs is provided via the power jumper contacts
  • The signal state of the outputs is shown by an LED
Technical specifications
Depth 698 mm
Assembly DIN rail
Width 12 mm
Height 100 mm
Number of digital outputs 2
Version output module
Logistics
Country of origin DE
Customs tariff number 85371098
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead, lead monoxide (lead oxide)
SVHC free No
RoHS conform Yes
