890-744 | WAGO
Socket, 4 pole, snap-in, push-in, 0.25-1.5 mm², gray, 890-744
Unit Price (€ / pc.)
6.3189 € *
Available: 21 pcs.
Total Price:
6.32 € *
Price list
Quantity
Price per unit*
1 pcs.
6.3189 €
10 pcs.
5.8191 €
50 pcs.
5.2955 €
100 pcs.
4.7600 €
*incl. VAT plus shipping costs
Subject to prior sale
Socket, 890-744, WAGO
Snap-in socket, 4-pole, code B, 1.50 mm², gray.
Features
- Protected against mismating
- Overvoltage category: III
- Pollution degree: 3
- Flammability class per UL94: V0
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage UL/CSA | 600 V | |
| Connection | push-in | |
| Rated voltage IEC | 400 V | |
| Colour | gray | |
| Pin number | 4 pole | |
| Type of locking | Yes | |
| Design | straight | |
| Assembly | snap-in | |
| Pin temperature | 85 °C | |
| Product type | socket | |
| Cable cross-section | 0.25-1.5 mm² | |
| Rated current UL/CSA | 12 A | |
| Rated current IEC | 16 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PL |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
