788-548 | WAGO

Coupling relay 2 Form C (NO/NC), 115 V (AC), 8 A, 250 V (AC), 788-548

Order No.: 43P2320
EAN: 4050821226819
MPN:
788-548
Series: 788
788-548 WAGO Coupling Relays Image 1
788-548 WAGO Coupling Relays Image 2
788-548 WAGO Coupling Relays Image 3
Image may differ
Unit Price (€ / pc.)
27.1082 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
27.11 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
27.1082 €

Relay module, 788-548, WAGO

Relay module, Nominal input voltage: 115 VAC, 2 changeover contacts, Limiting continuous current: 8 A, with manual operation, Red status indicator, Module width: 15 mm.

Technical specifications
Filter Property Value
Connection push-in
Product type coupling relay
Contact material AgNi
Coil voltage (AC) 115 V
Contact type 2 Form C (NO/NC)
Rated current 8 A
Rated voltage (AC) 250 V
Logistics
Property Value
Customs tariff number 85364900
Country of origin DE
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
