750-354 | WAGO
EtherCAT fieldbus coupler, 100 Mbit/s, 24 VDC, 750-354
Unit Price (€ / pc.)
262.3117 € *
Standard delivery time from the manufacturer is: 5 Weeks
Fieldbus coupler, 750-354, WAGO
This fieldbus coupler connects the EtherCAT to the modular WAGO I/O System, then it detects all connected I/O modules and creates a local process image. This process image may include a mixed arrangement of analog (word-by-word data transfer) and digital (bit-by-bit data transfer) modules.
Features
- High performance
- Flexible topology
- Simple configuration
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | fieldbus coupler | |
| Interfaces | EtherCAT | |
| Data transmission rate | 100000000 mb/s | |
| Voltage | 24 VDC | |
| Width | 49.5 mm | |
| Height | 96.8 mm | |
| Depth | 71.9 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85176200 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Substance description | boron trioxide, lead monoxide, lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
