POS300JT-77-75KAA | Vitrohm
Metal oxide film resistor, 75 kΩ, ±5 %, POS300JT-77-75KAA
Order No.: 29E649
EAN: 4099879674715
MPN:
POS300JT-77-75KAA
Unit Price (€ / pc.)
0.2190 € *
Standard delivery time from the manufacturer is: 10 Weeks
Metal oxide film resistor, POS300JT-77-75KAA, Vitrohm
Metal Oxide Film Resistor, 75 kΩ, ±5 %
Features
- High power dissipation 4[W]
- “Z” preforming ; Other preforming available
- RoHs & REACH Compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 6 mm | |
| Isolation voltage | 500 V | |
| Temperature coefficient | ±200 ppm/K | |
| max. operating temperature | 250 °C | |
| Tolerance | ±5 % | |
| Length | 16.5 mm | |
| Assembly | THT | |
| min. operating temperature | -55 °C | |
| Design | axial | |
| ohmic resistance | 75 kΩ | |
| Version | metal oxide resistor |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bulk with 500 pieces |
| Customs tariff number | 85332100 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
