VR68000008204JAC00 | Vishay
Metal film resistor, 8.2 MΩ, 1 W, ±5 %, VR68000008204JAC00
Unit Price (€ / pc.)
0.6069 € *
Available: 1,269 pcs.
Total Price:
6.07 € *
Price list
Quantity
Price per unit*
10 pcs.
0.6069 €
50 pcs.
0.5117 €
250 pcs.
0.4522 €
1000 pcs.
0.4046 €
2000 pcs.
0.3570 €
*incl. VAT plus shipping costs
Subject to prior sale
Metal glaze resistor, VR68000008204JAC00, Vishay
The VR68000008204JAC00 is a high ohmic/high voltage metal glaze leaded resistor deposited on a high grade ceramic body. After a helical groove has been cut in the resistive layer, tinned electrolytic copper wire is welded to the end-caps. This resistor is coated with a light blue lacquer which provides electrical, mechanical, and climatic protection. This coating is not resistant to aggressive fluxes and cleaning solvents.
Applications
- High humidity environment
- Power supplies
- Automotive electronics
- White goods
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 8.2 MΩ | |
| Tolerance | ±5 % | |
| diameter | 6.8 mm | |
| Isolation voltage | 700 V | |
| Temperature coefficient | ±200 ppm/K | |
| max. operating temperature | 155 °C | |
| Power | 1 W | |
| min. operating temperature | -55 °C | |
| Version | metal film resistor | |
| Assembly | THT | |
| Design | axial | |
| Length | 18 mm |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Ammopack with 500 pieces |
| Country of origin | IN |
| Customs tariff number | 85332100 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
