VR68000005104JAC00 | Vishay

Metal film resistor, 5.1 MΩ, 1 W, ±5 %, VR68000005104JAC00

Order No.: 31E282
EAN: 4099879679949
MPN:
VR68000005104JAC00
Series: VR68
VR68000005104JAC00 Vishay Wirewound Resistors Image 1
VR68000005104JAC00 Vishay Wirewound Resistors Image 2
Image may differ
Unit Price (€ / pc.)
0.4760 € *
Available: 49 pcs.
Total Price:
0.48 € *
Price list
Quantity
Price per unit*
1 pcs.
0.4760 €
50 pcs.
0.4284 €
250 pcs.
0.3570 €
500 pcs.
0.3213 €
1000 pcs.
0.2975 €
2000 pcs.
0.2773 €
*incl. VAT plus shipping costs
Subject to prior sale

Metal glaze resistor, VR68 5% AC 5M1, Vishay

The VR68 5% AC 5M1 is a high ohmic/high voltage metal glaze leaded resistor deposited on a high grade ceramic body. After a helical groove has been cut in the resistive layer, tinned electrolytic copper wire is welded to the end-caps. This resistor is coated with a light blue lacquer which provides electrical, mechanical, and climatic protection. This coating is not resistant to aggressive fluxes and cleaning solvents.

Applications

  • High humidity environment
  • Power supplies
  • Automotive electronics
  • White goods
Technical specifications
Filter Property Value
max. operating temperature 155 °C
Version metal film resistor
Assembly THT
Design axial
Power 1 W
diameter 6.8 mm
Length 18 mm
Isolation voltage 700 V
Temperature coefficient ±200 ppm/K
min. operating temperature -55 °C
Tolerance ±5 %
ohmic resistance 5.1 MΩ
Logistics
Property Value
Original Packaging Ammopack with 500 pieces
Country of origin IN
Customs tariff number 85332100
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
