BYS11-90 | Vishay
Schottky rectifier diode, 90 V (RRM), 1.5 A, DO-214AC, BYS11-90
Unit Price (€ / pc.)
0.4284 € *
Standard delivery time from the manufacturer is: On Request
Schottky diode, BYS11-90, Vishay
Surface-mount Schottky barrier rectifier.
Features
- Low profile package
- Ideal for automated placement
- Guardring for overvoltage protection
- Low power loss, high efficiency
- Very low switching losses
- High surge capability
Applications
- High frequency inverters
- Switch mode power supply
- Freewheeling applications
- O-ring diode
- DC/DC converters
- Reverse battery protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | SMD | |
| Junction temperature (max.) | 150 °C | |
| Number of diodes | 1 | |
| Version | schottky rectifier diode | |
| Forward Current | 1.5 A | |
| max. operating temperature | 150 °C | |
| Voltage V RRM (peak reverse voltage) | 90 V | |
| Enclosure | DO-214AC | |
| Junction temperature (min.) | -55 °C | |
| min. operating temperature | -55 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85411000 |
| Original Packaging | Reel with 1,800 pieces |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 6/8/11 |
| SVHC free | Yes |
| RoHS conform | Yes |
