MKP1848C53012JK2 | Vishay
MKP film capacitor, 3 µF, ±5 %, 1.2 kV (DC), PP, 40 mm, MKP1848C53012JK2
Order No.: 67D8520
EAN: 4099879862204
MPN:
MKP1848C53012JK2
Unit Price (€ / pc.)
3.5462 € *
Standard delivery time from the manufacturer is: 12 Weeks
Film capacitor, MKP1848C53012JK2, Vishay
MKP 1848C is a high density DC-link capacitor, with high ripple current capability, low ESR and low ESL.
Features
- Reverse Battery Protection
- Mirror Image Insertion Protection
- Internal Short Circuit and Thermal Overload Protection
Applications
- UPS
- Battery chargers
- Motor drives
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 40 mm | |
| Number of pins | 2 | |
| Design | radial | |
| max. operating temperature | 105 °C | |
| Capacity | 3 µF | |
| Dielectric material | PP | |
| Width | 18 mm | |
| Height | 28 mm | |
| min. operating temperature | -55 °C | |
| Tolerance | ±5 % | |
| Rated voltage (DC) | 1.2 kV | |
| Length | 32 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PT |
| Original Packaging | Bulk with 80 pieces |
| Customs tariff number | 85322900 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
