MAL213814153E3 | Vishay
Electrolytic capacitor, 15000 µF, 10 V (DC), ±20 %, axial, Ø 21 mm, MAL213814153E3
Unit Price (€ / pc.)
5.2122 € *
Standard delivery time from the manufacturer is: 8 Weeks
Electrolytic capacitor, MAL213814153E3, VISHAY
Aluminum electrolytic capacitor - Axial
Features
- Axial leads
- Rated capacitance 15000 µF
- Polarized aluminum electrolytic
- Rated voltage 10 V DC
Applications
- Automotive electronics
- Audio signal
- Smoothing, filtering and buffering
- Coupling, decoupling and timing
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 21 mm | |
| ESR (Equivalent Series Resistance) | 63 mΩ | |
| Rated voltage (DC) | 10 V | |
| max. operating temperature | 105 °C | |
| Tolerance | ±20 % | |
| Length | 38 mm | |
| Capacity | 15000 µF | |
| min. operating temperature | -40 °C | |
| Ripple current | 2.2 A | |
| Design | axial | |
| Version | polar |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bulk with 100 pieces |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
