GRC00PB4711CTNL | Vishay

Electrolytic capacitor, 470 µF, 16 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm, GRC00PB4711CTNL

Order No.: 12D4822
EAN: 4099879868749
MPN:
GRC00PB4711CTNL
Series: GRC
GRC00PB4711CTNL Vishay Electrolytic Capacitors Image 1
GRC00PB4711CTNL Vishay Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
0.1178 € *
Available: 5,960 pcs.
Total Price:
0.12 € *
Price list
Quantity
Price per unit*
1 pcs.
0.1178 €
10 pcs.
0.1059 €
100 pcs.
0.0952 €
500 pcs.
0.0774 €
1000 pcs.
0.0702 €
*incl. VAT plus shipping costs
Subject to prior sale

Electrolytic capacitor in aluminum can, type Vishay GRC.

For vertical mounting

Rated voltage 16 VDC.

Technical specifications
Filter Property Value
Grid 3.5 mm
max. operating temperature 105 °C
Ripple current 310 mA
min. operating temperature -40 °C
Version polar
Rated voltage (DC) 16 V
Tolerance ±20 %
Capacity 470 µF
Length 11.5 mm
diameter 8 mm
Design radial
Logistics
Property Value
Country of origin CN
Customs tariff number 85322200
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
