GRC00JG2221V00L | Vishay

Electrolytic capacitor, 2200 µF, 35 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 16 mm, GRC00JG2221V00L

Order No.: 12D4856
EAN: 4099879868909
MPN:
GRC00JG2221V00L
Series: GRC
GRC00JG2221V00L Vishay Electrolytic Capacitors Image 1
GRC00JG2221V00L Vishay Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
0.8092 € *
Available: 1,143 pcs.
Total Price:
0.81 € *
Price list
Quantity
Price per unit*
1 pcs.
0.8092 €
25 pcs.
0.6664 €
100 pcs.
0.5474 €
250 pcs.
0.4760 €
1000 pcs.
0.4165 €
*incl. VAT plus shipping costs
Subject to prior sale

Electrolytic capacitor in aluminum can, type Vishay GRC.

For vertical mounting

Rated voltage 35 VDC.

Technical specifications
Filter Property Value
Rated voltage (DC) 35 V
Capacity 2200 µF
diameter 16 mm
Grid 7.5 mm
Length 25 mm
Version polar
Design radial
min. operating temperature -40 °C
Tolerance ±20 %
max. operating temperature 105 °C
Ripple current 1.26 A
Logistics
Property Value
Country of origin CN
Customs tariff number 85322200
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
