T60404-B4658-X029 | Vacuumschmelze
Pulse current transformer, 20 Hz, 300 Hz, 35 A
Unit Price (€ / pc.)
4.5458 € *
Standard delivery time from the manufacturer is: 12 Weeks
Pulse current transformer, T60404-B4658-X029, Vacuumschmelze
Used for sensing and monitoring sine or square wave unipolar or bipolar currents. With electrical isolation; Frequency range: 20 Hz to 300 kHz (optimization by adaptation of the burden resistance).
Winding type transformer, T6040-B4658-X.
Technical attributes (type, max. primary current rms, max. secondary voltage time face integral, transformer ratio): T60404-B4658-X029, 35 A, 200 µVs, 1 : 100, 4.5 kV
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 70 °C | |
| Length | 16.8 mm | |
| Rated current | 35 A | |
| Voltage | 300 V | |
| min. operating temperature | -25 °C | |
| Frequency | 100 kHz | |
| Height | 19 mm | |
| Version | pulse current transformer |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Original Packaging | Bulk with 441 pieces |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
