PMR 411 | TWK-ELEKTRONIK
Rotary position encoder, PMR 411, 4.0 kohm, 0.5 W, 95°
Active
Product by TWK-ELEKTRONIK at Bürklin Elektronik
Rotary position encoders, type TWK PMR 411
type: PMR 411
With integrated reset spring, sealed housing. Resistant against oils, fuels, splash water, and defrosting agents (IP 65).
Connecting cable: approx. 280 mm.
Measuring range: 95°. Mechanical stop at 125°.
Resistance: 4.0 kohm.
Linearity: 1.5 %.
Operating temperatures: - 40 to +125 °C. Rating: 0.5 W.
Type: PMR 403, rotary position encoder
| Version | Rotary position encoder |
| Country of origin | FR |
| Customs tariff number | 90318020 |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
