TSPC 240-124UPS | TRACO POWER
Power supply, 24 VDC, 10 A, 240 W, TSPC 240-124UPS
Unit Price (€ / pc.)
474.7029 € *
Available in 7 Days: 107 pcs. - if ordered today
Total Price:
474.70 € *
Price list
Quantity
Price per unit*
1 pcs.
474.7029 €
10 pcs.
427.2457 €
*incl. VAT plus shipping costs
Subject to prior sale
Power supply, TSPC 240-124UPS, Traco
This power supply provides an integrated professional battery management system for charging and monitoring an external lead-acid battery. The result is a complete DC UPS system in a compact housing that requires no additional parts. The externally connected 12 V battery is charged by the power supply and kept in the state of charge. To avoid overcharging the battery, an external temperature sensor automatically regulates the battery voltage to the required end-of-charge voltage.
Features
- Battery protection for overvoltage, deep discharge, short circuit and polarity reversal
- Alarm outputs for input, output and battery status
- Remote On/Off for UPS function and power supply
- Controlled end-of-charge voltage through battery temperature sensor
- International security
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Depth | 100 mm | |
| Height | 114 mm | |
| Power | 240 W | |
| Output voltage DC | 24 VDC | |
| efficiency | 91 % | |
| Degree of protection (IP) | IP20 | |
| Output current | 10 A | |
| Number of outputs | 1 | |
| Width | 120 mm | |
| Input voltage AC | 85-132 VAC, 187-264 VAC |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85043180 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
