TSP 600-136 | TRACO POWER
Power supply, 36 to 42 VDC, 16.5 A, 600 W, TSP 600-136
Unit Price (€ / pc.)
497.1939 € *
Available in 7 Days: 32 pcs. - if ordered today
Total Price:
497.19 € *
Price list
Quantity
Price per unit*
1 pcs.
497.1939 €
10 pcs.
447.4519 €
*incl. VAT plus shipping costs
Subject to prior sale
Power supply, TSP 600-136, Traco
The TSP 600-136 power supply is designed for reliable operation in harsh conditions on the factory floor. High immunity to electrical noise and rugged metal enclosure make this module the best choice for powering sensitive loads in industrial process control systems, machine tools or other demanding industrial applications. It provides a DC OK signal and an external shutdown function.
Features
- Rugged metal housing for harsh industrial environments
- Shock and vibration resistant
- Industrial operating temperature range: -25 °C to +70 °C
- Adjustable output voltage
- Protection against short circuit, overvoltage and overtemperature
- Power OK signal, remote control on/off
Technical specifications
| Filter | Property | Value |
|---|---|---|
| efficiency | 87 % | |
| Output current | 16.5 A | |
| Width | 165 mm | |
| Power | 600 W | |
| Number of outputs | 1 | |
| Input voltage AC | 85-132 VAC, 187-264 VAC | |
| Height | 125 mm | |
| Depth | 125 mm | |
| Degree of protection (IP) | IP20 | |
| Output voltage DC | 36 to 42 VDC |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
