TSP 140-112 EX | TRACO POWER
Power supply, 12 to 14 VDC, 12 A, 144 W, TSP 140-112 EX
Unit Price (€ / pc.)
207.5598 € *
Available in 7 Days: 285 pcs. - if ordered today
Total Price:
207.56 € *
Price list
Quantity
Price per unit*
1 pcs.
207.5598 €
10 pcs.
186.7943 €
*incl. VAT plus shipping costs
Subject to prior sale
Power supply, TSP 140-112 EX, Traco
The TSP 140-112 EX power supply is designed for reliable operation in harsh conditions on the factory floor. High immunity to electrical noise and rugged metal housing make this module the best choice for powering sensitive loads in industrial process control systems, machine tools or other demanding industrial applications. It provides a DC-OK signal and an external shutdown function.
Features
- Rugged metal housing for harsh industrial environments
- Shock and vibration resistant
- Industrial operating temperature range: -25 °C to +70 °C
- Adjustable output voltage
- Protection against short circuit, overvoltage and overtemperature
- Power OK signal, remote control on/off
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Width | 54 mm | |
| Power | 144 W | |
| Output current | 12 A | |
| Degree of protection (IP) | IP20 | |
| Input voltage AC | 85-132 VAC, 187-264 VAC | |
| Output voltage DC | 12 to 14 VDC | |
| Height | 110 mm | |
| efficiency | 87 % | |
| Depth | 110 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| Substance description | Lead |
