TSP 090-148 EX | TRACO POWER
Power supply, 48 to 56 VDC, 2 A, 96 W, TSP 090-148 EX
Unit Price (€ / pc.)
153.2601 € *
Available in 7 Days: 156 pcs. - if ordered today
Total Price:
153.26 € *
Price list
Quantity
Price per unit*
1 pcs.
153.2601 €
10 pcs.
137.9210 €
*incl. VAT plus shipping costs
Subject to prior sale
Power supply, TSP 090-148 EX, Traco
The TSP 090-148 EX power supply is designed for reliable operation in harsh conditions on the factory floor. High immunity to electrical noise and rugged metal housing make this module the best choice for powering sensitive loads in industrial process control systems, machine tools or other demanding industrial applications. It provides a DC OK signal and an external shutdown function.
Features
- Rugged metal housing for harsh industrial environments
- Shock and vibration resistant
- Industrial operating temperature range: -25 °C to +70 °C
- Adjustable output voltage
- Protection against short circuit, overvoltage and overtemperature
- Power OK signal, remote control on/off
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Output voltage DC | 48 to 56 VDC | |
| Depth | 110 mm | |
| Output current | 2 A | |
| Width | 35 mm | |
| Number of outputs | 1 | |
| Height | 110 mm | |
| Degree of protection (IP) | IP20 | |
| Power | 96 W | |
| efficiency | 87 % | |
| Input voltage AC | 85-264 VAC |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85043180 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
