TBLC 25-105 | TRACO POWER
Power supply, 5 to 5.5 VDC, 4 A, 20 W, TBLC 25-105
Unit Price (€ / pc.)
57.4651 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
57.47 € *
Price list
Quantity
Price per unit*
1 pcs.
57.4651 €
10 pcs.
51.7174 €
*incl. VAT plus shipping costs
Subject to prior sale
Switching power supply, TBLC 25-105, TRACO
These new DIN rail mount power supplies are designed for industrial and residential applications. They are less expensive than the existing TBL series, with similar electrical specifications. They also fully comply with the new standby power and efficiency requirements (ECO standard). They are designed for connection as Class II devices, so that the protective earth connection is not required. Due to their small dimensions, they can be mounted in depth in flat racks. Their dimensions comply with the DIN 43 880 standard.
Features
- Low profile housing, module depth only 59.5 mm
- Suitable for mounting in house installation panels
- Low output ripple and spikes
- Full compliance with ECO standard
- Suitable for household appliances
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Output voltage DC | 5 to 5.5 VDC | |
| Depth | 89.5 mm | |
| Number of outputs | 1 | |
| Degree of protection (IP) | IP20 | |
| efficiency | 82 % | |
| Power | 20 W | |
| Input voltage AC | 85-264 VAC | |
| Width | 36 mm | |
| Height | 59.5 mm | |
| Output current | 4 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
