TBLC 15-105 | TRACO POWER
Power supply, 5 to 5.5 VDC, 2.4 A, 12 W, TBLC 15-105
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
49.3969 € *
Available in 7 Days: 147 pcs. - if ordered today
Total Price:
49.40 € *
Price list
Quantity
Price per unit*
1 pcs.
49.3969 €
10 pcs.
44.4584 €
*incl. VAT plus shipping costs
Subject to prior sale
Switching power supply, TBLC 15-105, TRACO
These new power supplies for DIN rail mounting are designed for industrial and residential applications. They are less expensive than the existing TBL series, with similar electrical specifications. They also fully comply with the new standby power and efficiency requirements (ECO standard). They are designed for connection as Class II devices, so that the protective earth connection is not required. Due to their small dimensions, they can be mounted in depth in flat racks. Their dimensions comply with the DIN 43 880 standard.
Features
- Low profile housing, module depth only 59.5 mm
- Suitable for mounting in house installation panels
- Low output ripple and spikes
- Full compliance with ECO standard
- Suitable for household appliances
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 2.4 A | |
| Output voltage DC | 5 to 5.5 VDC | |
| Input voltage AC | 85-264 VAC | |
| Power | 12 W | |
| efficiency | 81 % | |
| Degree of protection (IP) | IP20 | |
| Width | 27 mm | |
| Height | 59.5 mm | |
| Depth | 89.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85043180 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
