TSR 1-2412 | TRACO POWER
DC converter, 4.6-36 VDC, 1 W, 1 output, 1.2 VDC, 74 % efficiency, TSR 1-2412
Unit Price (€ / pc.)
9.5557 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
9.56 € *
Price list
Quantity
Price per unit*
1 pcs.
9.5557 €
10 pcs.
8.5918 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco TSR 1-2412
The new TSR-1 series step-down switching regulators are drop-in replacement for inefficient 78xx linear regulators. A high efficiency up to 96 % allows full load operation up to +60°C ambient temperature without the need of any heat-sink or forced cooling. The TSR-1 switching regulators provide other significant features over linear regulators, i.e. better output accuracy (±2 %), lower standby current of 2 mA and no requirement of external capacitors. The high efficiency and low standby power consumption makes these regulators an ideal solution for many battery powered applications.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| efficiency | 74 % | |
| Output voltage DC | 1.2 VDC | |
| Output current | 1 A | |
| Design | SIP3 | |
| Length | 11.7 mm | |
| Width | 7.5 mm | |
| Input voltage AC | 4.6-36 VDC | |
| Power | 1 W | |
| Height | 10.1 mm | |
| Number of outputs | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
