TSR 1-0525SM | TRACO POWER
DC converter, 3.8-5.5 VDC, 3 W, 1 output, 2.5 VDC, 95.5 % efficiency, TSR 1-0525SM
Unit Price (€ / pc.)
10.9480 € *
Available in 10 days: 210 pcs. - if ordered today
Total Price:
10.95 € *
Price list
Quantity
Price per unit*
1 pcs.
10.9480 €
10 pcs.
9.8413 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco TSR 1-0525SM
The TSR-1SM series models of step-down switching regulators have a high efficiency up to 96 % which allows full load operation up to +65°C ambient temperature without the need of any heat transmission layer. Excellent output voltage accuracy (±2%) and low standby current (~1 A) are features that distinguish these switching regulators from linear regulators.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Output voltage DC | 2.5 VDC | |
| Power | 3 W | |
| efficiency | 95.5 % | |
| Length | 15.2 mm | |
| Height | 7.4 mm | |
| Input voltage AC | 3.8-5.5 VDC | |
| Width | 9.3 mm | |
| Number of outputs | 1 | |
| Output current | 1 A | |
| Design | SMD |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
