TSM 0515D | TRACO POWER
DC converter, 4.5-5.5 VDC, 0.9 W, 2 outputs, ±15 VDC, 79 % efficiency, TSM 0515D
Unit Price (€ / pc.)
11.0908 € *
Available in 7 Days: 60 pcs. - if ordered today
Total Price:
11.09 € *
Price list
Quantity
Price per unit*
1 pcs.
11.0908 €
10 pcs.
9.9722 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco TSM 0515D
The TSM series are isolated DC/DC converters with 1W output power implemented in a molded plastic package with a pin accuracy suitable for automated SMD-production. The devices can be soldered without any problems in a high temperature lead free solder process. With their small footprint these converters are the economical solution for point of load power conversion, ground loop elimination, noise reduction and digital interface applications.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 2 | |
| Output current | 30 mA | |
| Output voltage DC | ±15 VDC | |
| Input voltage AC | 4.5-5.5 VDC | |
| Power | 0.9 W | |
| efficiency | 79 % | |
| Design | SMD | |
| Isolation voltage | 1 kV | |
| Length | 15.2 mm | |
| Width | 8 mm | |
| Height | 7.1 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
