TMR 6-2410 | TRACO POWER
DC converter, 18-36 VDC, 4.3 W, 1 output, 3.3 VDC, 78 % efficiency, TMR 6-2410
Unit Price (€ / pc.)
23.5382 € *
Standard delivery time from the manufacturer is: 20 Weeks
Total Price:
23.54 € *
Price list
Quantity
Price per unit*
1 pcs.
23.5382 €
10 pcs.
21.1820 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC Converter, TMR 6-2410, TRACO POWER
The TMR-6 is a isolated 6W DC/DC converter module with regulated output, featuring wide 2:1 input voltage ranges. This product comes in a ultra-compact SIP-8 plastic package with a small footprint occupying only 2.0 cm² of board space. Further features include remote On/Off control and continuous short circuit protection. The very compact dimensions of ths converter makes it an ideal solution for space critical applications.
Features
- Wide 2:1 input voltage range
- Continuous shor-circuit protection
- High efficiency up to 86%
- Remote On/Off control
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 1300 mA | |
| Output voltage DC | 3.3 VDC | |
| Input voltage AC | 18-36 VDC | |
| Power | 4.3 W | |
| efficiency | 78 % | |
| Design | SIP8 | |
| Isolation voltage | 1.6 kV | |
| Length | 21.8 mm | |
| Width | 9.1 mm | |
| Height | 11.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
