TMR 3-1221WI | TRACO POWER

DC converter, 4.5-18 VDC, 3 W, 2 outputs, ±5 VDC, 80 % efficiency, TMR 3-1221WI

Order No.: 26K1558
MPN:
TMR 3-1221WI
Series: TMR 3WI
TMR 3-1221WI TRACO POWER DC/DC Converters Image 1
TMR 3-1221WI TRACO POWER DC/DC Converters Image 2
Image may differ
Unit Price (€ / pc.)
27.2629 € *
Standard delivery time from the manufacturer is: 20 Weeks
Total Price:
272.63 € *
*incl. VAT plus shipping costs
Subject to prior sale
10 pcs.
27.2629 €

DC/DC Converter, TMR 3-1221WI, TRACO POWER

The TMR 3-1221WI is an isolated 3W DC/DC converter with regulated output, featuring ultra-wide 4:1 input voltage range. The product comes in a ultra-compact SIP plastic package with a small footprint occupying only 2.0 cm² of board space. An excellent efficiency allows -40° to +85°C operation temperatures.

Features

  • Excellent load and line regulation
  • Remote On/Off control
  • Short-circuit protection
Technical specifications
Number of outputs 2
Output current 300 mA
Output voltage DC ±5 VDC
Input voltage AC 4.5-18 VDC
Power 3 W
efficiency 80 %
Design SIP8
Isolation voltage 1.6 kV
Length 21.8 mm
Width 9.1 mm
Height 11.2 mm
Logistics
Country of origin TW
Customs tariff number 85044095
Original Packaging Bar with 10 pieces
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
