TMR 2-4810E | TRACO POWER

DC converter, 36-75 VDC, 1.7 W, 1 output, 3.3 VDC, 71 % efficiency, TMR 2-4810E

Order No.: 26K2288
EAN: 7613441031859
MPN:
TMR 2-4810E
Series: TMR 2E
TMR 2-4810E TRACO POWER DC/DC Converters Image 1
TMR 2-4810E TRACO POWER DC/DC Converters Image 2
Image may differ
Unit Price (€ / pc.)
12.7330 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
12.73 € *
Price list
Quantity
Price per unit*
1 pcs.
12.7330 €
10 pcs.
11.4597 €
*incl. VAT plus shipping costs
Subject to prior sale

DC converters, type Traco TMR 2-..E.

2.0 W converter in SIL-8 package; Features: 2 :1 input ranges, regulated output voltage, sustained short circuit-proof, external On/Off. Control error: on input fluctuation max. 0.5 %, on load fluctuation max. 0.75 %. Residual ripple; max. 50 mVpp. Operating temperatures: –40 to +85 °C. I/O test voltage 1000 VDC. Insulation resistance: min. 1.0 Gohm. MTBF (at +25 °C): min. 1.0 million h.

Input voltage range from 36 to 75 VDC.

Technical attributes (type, output voltage, output current, efficiency): TMR 2-4810E, 3.3 VDC, 500 mA, 71 %

Technical specifications
Filter Property Value
Number of outputs 1
Output current 500 mA
Output voltage DC 3.3 VDC
Input voltage AC 36-75 VDC
Power 1.7 W
efficiency 71 %
Design SIP8
Isolation voltage 1 kV
Length 21.8 mm
Width 9.3 mm
Height 11.2 mm
Logistics
Property Value
Customs tariff number 85044095
Country of origin TW
Compliance
Property Value
RoHS conform Yes
Substance description Lead
Date of RoHS guidelines 3/31/15
SVHC free No
