THI 3-1223 | TRACO POWER
DC converter, 10.8-13.2 VDC, 3 W, 2 outputs, ±15 VDC, 60 % efficiency, THI 3-1223
Unit Price (€ / pc.)
32.0824 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
32.08 € *
Price list
Quantity
Price per unit*
1 pcs.
32.0824 €
10 pcs.
28.8694 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco THI 3-1223
The THI 3 series is a new range of high isolation DC/DC converters with a reinforced insulation system. The I/O- isolation voltage is specified for 4000VACrms. The circuit is encapsulated in a DIP-24 package. There are 15 models available for 5, 12 and 24VDC input voltage and single or dual output voltage. The THI-3 DC/DC converters offer a cost effective solution for applications in industrial controls and medical instrumentation requiring a certified supplementary or reinforced insulation system to comply with industrial or latest medical safety standards.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 2 | |
| Output current | 100 mA | |
| Output voltage DC | ±15 VDC | |
| Input voltage AC | 10.8-13.2 VDC | |
| Power | 3 W | |
| efficiency | 60 % | |
| Design | DIP24 | |
| Isolation voltage | 4 kV | |
| Length | 31.8 mm | |
| Width | 20.3 mm | |
| Height | 10.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
