THD 15-2411N | TRACO POWER
DC converter, 18-36 VDC, 15 W, 1 output, 5.1 VDC, 90 % efficiency, THD 15-2411N
Unit Price (€ / pc.)
47.9451 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
47.95 € *
Price list
Quantity
Price per unit*
1 pcs.
47.9451 €
10 pcs.
43.1375 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC Converter, THD 15-2411N, TRACO POWER
The THD 15-2411N provides 15 W output power out of a very compact shielded metal case that occupies only 1 inch² of board space. The converter works with a high efficiency over the full load range and draws a very low input current at no load conditions. It has a wide 2:1 input voltage range and a precisely regulated output voltage.
Features
- Industry standard pinout
- Remote On/Off control
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 3 A | |
| Output voltage DC | 5.1 VDC | |
| Input voltage AC | 18-36 VDC | |
| Power | 15 W | |
| efficiency | 90 % | |
| Design | DIP24 | |
| Isolation voltage | 1.6 kV | |
| Length | 31.8 mm | |
| Width | 20.3 mm | |
| Height | 10.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
