TES 5-4811WI | TRACO POWER
DC converter, 18-75 VDC, 5 W, 1 output, 5 VDC, 80 % efficiency, TES 5-4811WI
Unit Price (€ / pc.)
41.3287 € *
Available in 7 Days: 20 pcs. - if ordered today
Total Price:
41.33 € *
Price list
Quantity
Price per unit*
1 pcs.
41.3287 €
10 pcs.
37.1875 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco TES 5-4811WI
The TES-5WI series is a family of high performance 5W dc/dc-converter modules in a low profile SMD package with compact dimensions. The 14 modules feature ultrawide 4:1 input ranges with tightly regulated output voltage. High efficiency allows an operating temperature range of –40 to +71°C at full load. Further features a e built-in EMI-filter to meet EN 55022 class A without external components and remote On/Off control. The products comply with IPC J-STD-020D and are qualified for high temperature lead-free reflow solder process
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 1 A | |
| Output voltage DC | 5 VDC | |
| Input voltage AC | 18-75 VDC | |
| Power | 5 W | |
| efficiency | 80 % | |
| Design | SMD | |
| Isolation voltage | 1.5 kV | |
| Length | 33.4 mm | |
| Width | 20.6 mm | |
| Height | 10.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
