TEP 100-2418-CMF | TRACO POWER
DC converter, 18-36 VDC, 100 W, 1 output, 48 VDC, 92 % efficiency, TEP 100-2418-CMF
Unit Price (€ / pc.)
283.1962 € *
Available in 10 days: 42 pcs. - if ordered today
Total Price:
283.20 € *
Price list
Quantity
Price per unit*
1 pcs.
283.1962 €
10 pcs.
254.8623 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco TEP 100-2418-CMF
The TEP 100 Series is a family of isolated high performance dc-dc converter modules with wide 2:1 input voltage ranges which come in a rugged, sealed industry standard half brick package. A very high efficiency allows full power operation without forced air cooling at 25°C. This temperature can be increased to 40°C with optional mounted heat-sink or up to 60°C when mounted on an iron base plate. The very wide input voltage range and reverse input voltage protection make these converters interesting solution for battery operated systems. Typical applications are in telecom/datacom and industry control.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Output current | 2.1 A | |
| Number of outputs | 1 | |
| Length | 85.1 mm | |
| Power | 100 W | |
| Output voltage DC | 48 VDC | |
| efficiency | 92 % | |
| Width | 61 mm | |
| Isolation voltage | 2.25 kV | |
| Input voltage AC | 18-36 VDC | |
| Height | 38.9 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
