TEL 8-2423 | TRACO POWER
DC converter, 18-36 VDC, 8 W, 2 outputs, ±15 VDC, 86 % efficiency, TEL 8-2423
Unit Price (€ / pc.)
26.2157 € *
Standard delivery time from the manufacturer is: 2 Weeks
DC/DC Converter, TEL 8-2423, TRACO POWER
The TEL 8-2423 is an isolated 8 W converter which comes in a very compact DIP-16 metal package. It offers a 2:1 input voltage range and features a high efficiency which allows an operation temperature of up to +70°C at full load.
Features
- Built-in EN 55032 class A filter
- Protection against short circuit
Applications
- IT
- Instrumentation
- Industrial electronics
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 2 | |
| Output current | 265 mA | |
| Output voltage DC | ±15 VDC | |
| Input voltage AC | 18-36 VDC | |
| Power | 8 W | |
| efficiency | 86 % | |
| Design | DIP16 | |
| Isolation voltage | 1.5 kV | |
| Length | 24.1 mm | |
| Width | 14 mm | |
| Height | 8.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
