TEL 2-1213 | TRACO POWER

DC converter, 9-18 VDC, 2 W, 1 output, 15 VDC, 80 % efficiency, TEL 2-1213

Order No.: 32C1168
EAN: 4099891303938
MPN:
TEL 2-1213
Series: TEL 2
TEL 2-1213 TRACO POWER DC/DC Converters
Image may differ
Unit Price (€ / pc.)
13.4589 € *
Standard delivery time from the manufacturer is: 14 Weeks
Total Price:
13.46 € *
Price list
Quantity
Price per unit*
1 pcs.
13.4589 €
10 pcs.
12.1142 €
*incl. VAT plus shipping costs
Subject to prior sale

DC/DC Converter, TEL 2-1213, TRACO POWER

The TEL 2-1213 is an isolated 2 W converter in a low profile DIP-16 package. Requiring only 3.25 cm² of space on the PCB it provides a complete DC/DC converter without the need of any external components.

Features

  • Low ripple and noise
  • Fully regulated output
  • Indefinite short circuit protection
  • Lead-free design -RoHS compliant
Technical specifications
Number of outputs 1
Output current 135 mA
Output voltage DC 15 VDC
Input voltage AC 9-18 VDC
Power 2 W
efficiency 80 %
Design DIP16
Isolation voltage 1.5 kV
Length 23.8 mm
Width 13.7 mm
Height 8 mm
Logistics
Country of origin TW
Customs tariff number 85044095
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
