TDR 3-1222SM | TRACO POWER
DC converter, 9-18 VDC, 3 W, 2 outputs, ±12 VDC, 82 % efficiency, TDR 3-1222SM
Unit Price (€ / pc.)
33.9745 € *
Available in 7 Days: 260 pcs. - if ordered today
Total Price:
33.97 € *
Price list
Quantity
Price per unit*
1 pcs.
33.9745 €
10 pcs.
30.5711 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco TDR 3-1222SM
The TDR-3 series is a family of compact 3 W dc/dc-converters with 2:1 input voltage ranges and tightly regulated output voltages even under no load conditions. The product is available in SMD-package or in DIP-package. They work with high efficiency over the full load range and come with a remote On/Off input. The usability in temperature ranges of up to 85°C, continuous short circuit protection and excellent immunity against environmental influences make these converters very reliable. A TDR-3 converter is the ideal solution for space critical high end applications in communication equipment, instrumentation and industrial electronics.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 2 | |
| Output current | 125 mA | |
| Output voltage DC | ±12 VDC | |
| Input voltage AC | 9-18 VDC | |
| Power | 3 W | |
| efficiency | 82 % | |
| Design | SMD | |
| Isolation voltage | 1.6 kV | |
| Length | 18.9 mm | |
| Width | 12.8 mm | |
| Height | 8.7 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
