TDR 2-2423WISM | TRACO POWER
DC converter, 9-36 VDC, 2 W, 2 outputs, ±15 VDC, 81 % efficiency, TDR 2-2423WISM
Unit Price (€ / pc.)
31.3208 € *
Available in 10 days: 40 pcs. - if ordered today
Total Price:
31.32 € *
Price list
Quantity
Price per unit*
1 pcs.
31.3208 €
10 pcs.
27.9055 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converter, TDR 2-2423WISM, TRACO POWER
The TDR 2-2423WISM is a compact 2 W DC/DC converter with a 4:1 input voltage range and tightly regulated output voltage even under no load conditions. It works with high efficiency over the full load range and comes with a remote On/Off input. The usability in temperature ranges of up to 85 °C without power derating, continuous short-circuit protection and excellent immunity against environmental influences make this converter very reliable. The TDR 2-2423WISM converter is the ideal solution for space-critical high-end applications in communication equipment, instrumentation and industrial electronics.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 2 | |
| Output current | 67 mA | |
| Output voltage DC | ±15 VDC | |
| Input voltage AC | 9-36 VDC | |
| Power | 2 W | |
| efficiency | 81 % | |
| Design | SMD | |
| Isolation voltage | 1.6 kV | |
| Length | 18.9 mm | |
| Width | 17.2 mm | |
| Height | 8.7 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
