TDN 5-0911WI | TRACO POWER
DC converter, 4.5-13.2 VDC, 5 W, 1 output, 5 VDC, 80 % efficiency, TDN 5-0911WI
Unit Price (€ / pc.)
29.2026 € *
Standard delivery time from the manufacturer is: 3 Weeks
DC/DC Converter, TDN 5-0911WI, TRACO POWER
The TDN 5-0911WI redefines the power density of high performance DC/DC converters. The cubical package of only 1.23 cm³ encloses a sophisticated circuit which provides 5 W output power without any compromise regarding reliability and functionality.It operates up to 50°C environment temperature at full load or up to 70°C with a 50% load de-rating
Features
- Fully regulated outputs
- Remote On/Off control
- Short-circuit protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 1 A | |
| Output voltage DC | 5 VDC | |
| Input voltage AC | 4.5-13.2 VDC | |
| Power | 5 W | |
| efficiency | 80 % | |
| Design | DIP8 | |
| Isolation voltage | 1.6 kV | |
| Length | 13.2 mm | |
| Width | 9.1 mm | |
| Height | 10.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
