TDN 3-2423WI | TRACO POWER
DC converter, 9-36 VDC, 3 W, 2 outputs, ±15 VDC, 82 % efficiency, TDN 3-2423WI
Unit Price (€ / pc.)
26.2395 € *
Standard delivery time from the manufacturer is: 3 Weeks
DC/DC Converter, TDN 3-2423WI, TRACO POWER
The TDN 3-2423WI is a 3 W fully regulated, high performance DC/DC converter. It comes in a compact cubical package of only 1.23 cm³. Full load operation is reliable up to 70°C environment temperature.
Features
- Fully regulated outputs
- Remote On/Off control
- Short-circuit protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 2 | |
| Output current | 100 mA | |
| Output voltage DC | ±15 VDC | |
| Input voltage AC | 9-36 VDC | |
| Power | 3 W | |
| efficiency | 82 % | |
| Design | DIP8 | |
| Isolation voltage | 1.6 kV | |
| Length | 13.2 mm | |
| Width | 9.1 mm | |
| Height | 10.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
