TCL 060-112DC | TRACO POWER
DC converter, 18-75 VDC, 60 W, 1 output, 12 VDC, 86 % efficiency, TCL 060-112DC
Unit Price (€ / pc.)
104.8271 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
104.83 € *
Price list
Quantity
Price per unit*
1 pcs.
104.8271 €
10 pcs.
94.3194 €
*incl. VAT plus shipping costs
Subject to prior sale
60 W converter with 18 to 75 VDC input, type TCL..DC.
Dimensions: W 45, H 75, D 100 mm. Weight: 265 g.
Technical attributes (type, output voltage/adjustment range, output current): TCL 060-112 DC, output 12 VDC/18 to 75 VDC, 5.0 A
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 5 A | |
| Output voltage DC | 12 VDC | |
| Input voltage AC | 18-75 VDC | |
| Power | 60 W | |
| efficiency | 86 % | |
| Design | DIN rail | |
| Isolation voltage | 1.5 kV | |
| Length | 100 mm | |
| Width | 45 mm | |
| Height | 75 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85044083 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
