TXLN 018-105 | TRACO POWER
Power supply, 5 VDC, 3 A, 15 W, TXLN 018-105
Unit Price (€ / pc.)
28.4886 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
28.49 € *
Price list
Quantity
Price per unit*
1 pcs.
28.4886 €
10 pcs.
25.6326 €
*incl. VAT plus shipping costs
Subject to prior sale
AC/DC Power Supply, TXLN 018-105, TRACO POWER
AC/DC-power supply 5 VDC, 30 A, metal case. This is an encased power supply designed for a wide range of cost critical applications. With a low profile metal case and screw terminal block connection, it is easy to install in any equipment.
Features
- Convection cooled (no-fan)
- Short circuit, overvoltage and overload protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Output current | 3 A | |
| Power | 15 W | |
| Width | 50.8 mm | |
| Depth | 28 mm | |
| efficiency | 78 % | |
| Output voltage DC | 5 VDC | |
| Length | 62 mm | |
| Input voltage AC | 85-264 VAC/120-375 VDC | |
| Number of outputs | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
