TPP 40-251 | TRACO POWER
Switching power supply, 24/5 VDC, 4 A, 40 W, TPP 40-251
Unit Price (€ / pc.)
91.0112 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
91.01 € *
Price list
Quantity
Price per unit*
1 pcs.
91.0112 €
10 pcs.
81.9077 €
*incl. VAT plus shipping costs
Subject to prior sale
Switching power supply, TPP 40-251, TRACO
The TPP 40 series 40 Watt AC/DC power supplies feature a reinforced double I/O isolation system in accordance with the latest medical safety standards (60601-3 3rd edition, 2 x MOPP).
Features
- Highest efficiency over the entire load range
- Protection class II prepared
- Operation up to 5000m altitude
- Adjustable output voltage
- 3 years product warranty
Technical specifications
Depth | 34.5 mm | |
Output voltage DC | 24/5 VDC | |
Output current | 4 A | |
Width | 60.5 mm | |
Power | 40 W | |
Length | 102.4 mm | |
Number of outputs | 2 | |
efficiency | 86 % | |
Input voltage AC | 85-264 VAC/120-370 VDC |
Download
Logistics
Country of origin | TW |
Customs tariff number | 85044095 |
Compliance
Date of RoHS guidelines | 3/31/15 |
Substance description | Lead |
SVHC free | No |
RoHS conform | Yes |
