TMP 30316C | TRACO POWER
Power supply module, 3.3/5/12 VDC, 4 A, 24 W, TMP 30316C
Unit Price (€ / pc.)
93.5697 € *
Standard delivery time from the manufacturer is: 14 Weeks
Total Price:
93.57 € *
Price list
Quantity
Price per unit*
1 pcs.
93.5697 €
10 pcs.
84.2163 €
*incl. VAT plus shipping costs
Subject to prior sale
Power modules, type Traco TMP.
Flat, molded switching mode power supply module with short-circuit and overload protection
For chassis mounting, type TMP 30.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Depth | 25.6 mm | |
| Output voltage DC | 3.3/5/12 VDC | |
| Output current | 4 A | |
| Width | 63.8 mm | |
| Power | 24 W | |
| Length | 112 mm | |
| Number of outputs | 3 | |
| efficiency | 71 % | |
| Input voltage AC | 85-264 VAC/120-370 VDC |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85044083 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
