D12 M24 HWS | TRACO POWER
DC axial fan, 24 V, 120 x 120 x 38 mm, 177 m³/h, 41 dB, slide bearing, TRACO POWER D12 M24 HWS
Order No.: 82B4552
EAN: 4099889479362
MPN:
D12 M24 HWS
Unit Price (€ / pc.)
26.5846 € *
Standard delivery time from the manufacturer is: 4 Weeks
DC Axial fan, D12 M24 HWS, TRACO
The D12 M24 HWS Axial DC fan is a type of fan that blow air along the axis of the fan that is, the fancurved blades force air to move in parallel with the shaft on which the blades rotate. This fan can produce variable airflow and create higher flow rates than centrifugal fan.
Features
- Cable connector 300 mm, stranded wire stripped, tinned
- Housing and blades in thermoplastic - UL 94V-0
- Protected against blocking
- Reverse polarity protected
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 120 mm | |
| Volume flow | 177 m³/h | |
| Type of bearing | slide bearing | |
| speed | 2750 1/min | |
| Rated voltage | 24 V | |
| Version | DC axial fan | |
| Height | 120 mm | |
| Sound pressure level | 41 db | |
| Depth | 38 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 84145925 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
