TMM 40112 | TRACO POWER
AC/DC converter, 85-264 VAC/120-370 VDC, 40 W, 1 output, 12 VDC, TMM 40112
Unit Price (€ / pc.)
94.0814 € *
Available in 10 days: 312 pcs. - if ordered today
AC/DC Power Supply, TMM 40112, TRACO POWER
The TMM 40112 is a fully encapsulated 40 Watt AC/DC power supply module that features a reinforced/double I/O isolation system according to latest medical safety standards. The high efficiency and the use of highest grade components make it suitable for an operating temperature range of -40°C to +60°C without load derating.
Features
- Safety class II prepared
- Protection against over-temperature, overload and short circuit
Applications
- Medical devices
- Transportation systems
- Equipment in industrial and commercial environment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 3.33 A | |
| Output voltage DC | 12 VDC | |
| Input voltage AC | 85-264 VAC/120-370 VDC | |
| Power | 40 W | |
| efficiency | 84 % | |
| Design | PCB mounting | |
| Isolation voltage | 4 kV | |
| Length | 88.9 mm | |
| Width | 63.5 mm | |
| Height | 30 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
