LM392M | Texas Instruments
Dual operational amplifier/voltage comparator, SOIC-8, LM392M
Order No.: 41S4915
EAN: 4099879092151
MPN:
LM392M
Dual operational Amplifier/Voltage comparator, LM392M, TI
The LM392M consists of 2 independent building block circuits. One is a high gain, internally frequency compensated operational amplifier, and the other is a precision voltage comparator. Both the operational amplifier and the voltage comparator have been specifically designed to operate from a single power supply over a wide range of voltages.
Features
- Low input bias current
- Low input offset voltage
- Common-Mode input voltage
- Low supply current
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Enclosure | SOIC-8 | |
| Assembly | SMD | |
| Number of channels | 2 | |
| Version | operational amplifier/voltage comparator | |
| min. operating temperature | 0 °C | |
| max. operating temperature | 70 °C |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bar with 100 pieces |
| Country of origin | CN |
| Customs tariff number | 85423390 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
