MSPM0C1104SDDFR | Texas Instruments
ARM Cortex M0+ microcontroller, 32 bit, 24 MHz, TSOT-23-8, MSPM0C1104SDDFR
Mixed-Signal Microcontroller, MSPM0C1104SDDFR, Texas Instruments
The MSPM0C1104SDDFR is a powerful, highly integrated microcontroller (MCU) optimized for ultrasonic water and heat metering. It features a built-in Ultrasonic Sensing Solution (USS) module that delivers high accuracy across a broad range of flow rates. Designed for maximum integration, the USS module enables ultra-low-power metering while reducing system cost by requiring minimal external components. The MSPM0C1104SDDFR supports high-speed ADC-based signal acquisition, followed by efficient digital signal processing using the integrated Low-Energy Accelerator (LEA), providing a high-accuracy metering solution well-suited for battery-powered applications.
The USS module includes a programmable pulse generator (PPG) and a physical interface (PHY) with a low-impedance output driver to ensure optimal sensor excitation and precise impedance matching, minimizing zero-flow drift (ZFD). It also integrates a programmable gain amplifier (PGA) and a high-speed 12-bit, 8-MSPS sigma-delta ADC (SDHS) for accurate signal acquisition from industry-standard ultrasonic transducers.
Features
- High-performance analog peripherals
- Optimized low-power modes
- Intelligent digital peripherals
- Enhanced communication interfaces
- Clock system
- Data integrity
- Flexible I/O features
- Development support
Applications
- Battery charging and management
- Power supplies and power delivery
- Personal electronics
- Building security and fire safety
- Connected peripherals and printers
- Grid infrastructure
- Smart metering
- Communication modules
- Medical and healthcare
Filter | Property | Value |
---|---|---|
Enclosure | TSOT-23-8 | |
Assembly | SMD | |
Version | flash | |
Processor core | ARM Cortex M0+ | |
Core Size | 32 bit | |
Clock frequency | 24 MHz | |
Number of I/Os | 6 | |
Memory size | 16 KB | |
Data RAM Size | 1 KB | |
Protocol | DALI, I2C, IrDA, LINbus, SmartCard, SMBus, SPI, UART/USART | |
Voltage | 1.62-3.6 V | |
Number of pins | 8 | |
min. operating temperature | -40 °C | |
max. operating temperature | 125 °C |
