SLG109M025S1A5Q40K | Teapo
Electrolytic capacitor, 10000 µF, 25 V (DC), ±20 %, radial, pitch 10 mm, Ø 22 mm, SLG109M025S1A5Q40K
Unit Price (€ / pc.)
4.6886 € *
Available: 51 pcs.
Next delivery: 100 pcs. on 2026-01-29
Total Price:
4.69 € *
Price list
Quantity
Price per unit*
1 pcs.
4.6886 €
10 pcs.
4.1174 €
100 pcs.
3.6176 €
250 pcs.
3.4748 €
1000 pcs.
3.2606 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor in aluminum can, type LG.
With insulated package and snap-in connection
Rated voltage 25 VDC, type LG 25.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Capacity | 10000 µF | |
| Grid | 10 mm | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -40 °C | |
| Ripple current | 2.7 A | |
| Connection | snap-in | |
| diameter | 22 mm | |
| Tolerance | ±20 % | |
| Length | 40 mm | |
| Rated voltage (DC) | 25 V | |
| Version | polar | |
| Design | radial |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85332100 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
