KSY228M025S1A5L25K | Teapo

Electrolytic capacitor, 2200 µF, 25 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm, KSY228M025S1A5L25K

Order No.: 11D5168
EAN: 4099879866301
MPN:
KSY228M025S1A5L25K
SY2200UF/25V 13X25MM
Series: SY
KSY228M025S1A5L25K Teapo Electrolytic Capacitors Image 1
KSY228M025S1A5L25K Teapo Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
1.7017 € *
Available: 69 pcs.
Total Price:
1.70 € *
Price list
Quantity
Price per unit*
1 pcs.
1.7017 €
10 pcs.
1.0591 €
50 pcs.
0.9282 €
250 pcs.
0.8092 €
1000 pcs.
0.7021 €
*incl. VAT plus shipping costs
Subject to prior sale

Electrolytic capacitor in aluminum can, type Teapo SY.

With radial connections and low ESR

Rated voltage 25 VDC.

Technical specifications
Filter Property Value
Capacity 2200 µF
diameter 13 mm
max. operating temperature 105 °C
Length 25 mm
min. operating temperature -40 °C
Grid 5 mm
Ripple current 2.86 A
Design radial
Version polar
Rated voltage (DC) 25 V
Tolerance ±20 %
Logistics
Property Value
Customs tariff number 85322200
Country of origin TW
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
