KSS475M035S1A5B07K | Teapo

Electrolytic capacitor, 4.7 µF, 35 V (DC), ±20 %, radial, pitch 1.5 mm, Ø 4 mm, KSS475M035S1A5B07K

Order No.: 11D4830
EAN: 4099879866097
MPN:
KSS475M035S1A5B07K
SS035M4R70ST
Series: SS
KSS475M035S1A5B07K Teapo Electrolytic Capacitors Image 1
KSS475M035S1A5B07K Teapo Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
0.1904 € *
Available: 1,403 pcs.
Total Price:
0.19 € *
Price list
Quantity
Price per unit*
1 pcs.
0.1904 €
10 pcs.
0.1666 €
100 pcs.
0.1190 €
300 pcs.
0.0845 €
1000 pcs.
0.0714 €
*incl. VAT plus shipping costs
Subject to prior sale

Electrolytic capacitor, insulated aluminum can, type SS.

With radial connections

Rated voltage 35 VDC, type SS 35.

Technical specifications
Filter Property Value
Capacity 4.7 µF
diameter 4 mm
max. operating temperature 105 °C
Length 7 mm
min. operating temperature -40 °C
Grid 1.5 mm
Ripple current 24 mA
Design radial
Version polar
Rated voltage (DC) 35 V
Tolerance ±20 %
Logistics
Property Value
Customs tariff number 85322200
Country of origin CN
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
