KSE159M6R3S1UBN36K | Teapo

Electrolytic capacitor, 15000 µF, 6.3 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 18 mm, KSE159M6R3S1UBN36K

Order No.: 11D4980
EAN: 4099879866202
MPN:
KSE159M6R3S1UBN36K
Series: SS
KSE159M6R3S1UBN36K Teapo Electrolytic Capacitors Image 1
KSE159M6R3S1UBN36K Teapo Electrolytic Capacitors Image 2
Image may differ

Discontinued

Unit Price (€ / pc.)
0.8211 € *
Available: 260 pcs.
Total Price:
4.11 € *
Price list
Quantity
Price per unit*
5 pcs.
0.8211 €
25 pcs.
0.7378 €
125 pcs.
0.6664 €
500 pcs.
0.6069 €
1000 pcs.
0.5474 €
*incl. VAT plus shipping costs
Subject to prior sale

Electrolytic capacitor, insulated aluminum can, type Teapo SE.

With radial connections

Rated voltage 6.3 VDC, type SE 006.

Technical specifications
Filter Property Value
Capacity 15000 µF
diameter 18 mm
max. operating temperature 105 °C
Length 36 mm
min. operating temperature -40 °C
Grid 7.5 mm
Ripple current 2.1 A
Design radial
Version polar
Rated voltage (DC) 6.3 V
Tolerance ±20 %
Logistics
Property Value
Customs tariff number 85322200
Country of origin CN
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 6/8/11
