2141826-5 | TE Connectivity
Uninsulated flat plug sleeve, 0.63 x 0.63 mm, 0.13 to 0.17 mm², AWG 26 to 25, 2141826-5
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
0.2142 € *
Available in 12 Days: 192,000 pcs. - if ordered today
Total Price:
203.49 € *
Price list
Quantity
Price per unit*
950 pcs.
0.2142 €
2200 pcs.
0.2106 €
*incl. VAT plus shipping costs
Subject to prior sale
Plug sleeve, 2141826-5, TE Connectivity
Automotive terminals, Receptacle, Mating tab width 0.63 mm, Tab thickness 0.63 mm, 26-25 AWG Wire size.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | flat plug sleeve | |
| Suitable for | 0.63 x 0.63 mm | |
| Isolated | No | |
| Connection | crimp connection | |
| Cable cross-section | 0.13 to 0.17 mm² | |
| AWG cross-section | AWG 26 to 25 | |
| Length | 14.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85389099 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
