2-1625931-8 | TE Connectivity
Cermet potentiometer, 1 kΩ, 2 W, linear, solder pin, 2-1625931-8
Order No.: 40P7446
EAN: 4099879970510
MPN:
2-1625931-8
404802692035
Unit Price (€ / pc.)
24.0975 € *
Available in 5 Days: 100 pcs. - if ordered today
Total Price:
1,204.88 € *
Price list
Quantity
Price per unit*
50 pcs.
24.0975 €
100 pcs.
22.9075 €
*incl. VAT plus shipping costs
Subject to prior sale
Potentiometer, 2-1625931-8, TE
This potentionmeter is available with cermet resistance elements. This choice means that components offer excellent electrical and thermal stability, reliability, low noise and long life which makes them most suitable for the majority of professional applications.
Features
- Strong construction
- Sealed to military standard
- 2 W power rating
- Rugged terminations
- Panel sealed (MC1)
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 1 kΩ | |
| Mechanic rotary range | 270 ° | |
| axle diameter | 6.32 mm | |
| max. number of revolutions | 1 | |
| Length | 19.05 mm | |
| Track Taper | linear | |
| Connection | solder pin | |
| Power | 2 W | |
| Width | 12.7 mm | |
| Assembly | straight | |
| Rotary range, electrical | 270 ° | |
| Version | cermet potentiometer |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Original Packaging | Bulk with 50 pieces |
| Customs tariff number | 85334010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
